FAG 7214B.TVP.UA Angular Contact Ball Bearing
The FAG 7214B.TVP.UA Angular Contact Ball Bearing is designed for high-precision applications requiring a high contact angle and robust load capacities. This bearing features a solid cage made of glass-fiber reinforced polyamide for optimal performance.
Manufacturer: FAG
Type: Angular Contact Ball Bearing
Model: 7214B.TVP.UA
Technical Information:
- Design: UA, bearing set with small axial internal clearance
- Bore Diameter: 70 mm
- Outer Diameter: 125 mm
- Width: 24 mm
- Contact Angle: 40°
- Dynamic Load Rating (Cr): 74,000 N
- Static Load Rating (C0r): 62,000 N
- Fatigue Load Rating: 4,300 N
- Limiting Speed: 7,200 1/min
- Reference Speed: 5,400 1/min
- Cage: TVP; Solid cage made of glass-fiber reinforced polyamide PA66
