FAG NJ 308 E.TVP2 CYLINDRICAL ROLLER BEARING
The FAG NJ 308 E.TVP2 is a precision-engineered cylindrical roller bearing designed for high radial load capacity and excellent performance in demanding applications. Equipped with a solid window cage made from PA66, this bearing ensures durability, efficiency, and reliable operation at high speeds.
Manufacturer: FAG
Type: Cylindrical Roller Bearing
Model: NJ 308 E.TVP2
Technical Information
- Bore Diameter (d): 40 mm
- Outer Diameter (D): 90 mm
- Width (B): 23 mm
- Dynamic Load Rating (Cr): 96,000 N
- Static Load Rating (C0r): 79,000 N
- Fatigue Load Rating (Radial): 13,700 N
- Limiting Speed: 10,900 rpm
- Reference Speed: 7,100 rpm
- Cage: TVP2, Solid Window Cage made from PA66
