Manufacturer: FESTO

Type: Parallel gripper

Model: DHPS-35-A

Part No.: 1254052

Housing material: Wrought aluminum alloy, Hard-anodized

Stroke per gripper jaw: 12.5 mm

Number of gripper jaws: 2

Mode of operation: Double-acting

Position sensing: For proximity sensor

Total gripping force at 6 bar, opening: 970 N

Operating Pressure: 2 … 10 bar

Fluid: Air

Ambient Temperature: -5 … 60 °C

Pneumatic connection: G1/8
