FESTO CPE14-M1H-5J-1/8 DOUBLE SOLENOID VALVE WITH COIL

The FESTO CPE14-M1H-5J-1/8 is a high-performance double solenoid valve designed for precision air flow control in demanding pneumatic systems. Featuring a bistable 5/2 piston slide mechanism, this valve ensures reliable switching and long operational life. It is supplied with the FESTO MSZB-3-24V DC solenoid coil, providing dependable electrical actuation with IP65 protection.

Manufacturer: FESTO
Type: Double Solenoid Valve
Model: CPE14-M1H-5J-1/8
Part No.: 162206

Valve Technical Information

• Fluid: Air
• Design: Piston Slide
• Function: 5/2 Bistable
• Type of Actuation: Electrically
• Operating Pressure: 2 … 8 bar
• Nominal Flow Rate: 750 l/min
• Pneumatic Connection: G1/8
• Material: Die-cast Aluminum
• Ambient Temperature: -10 / 50 °C

Attachment: FESTO MSZB-3-24V DC SOLENOID COIL

Manufacturer: FESTO
Type: Solenoid Coil
Model: MSZB-3-24V DC
Part No.: 119801 D

Coil Technical Information

• Supply Voltage: 20.4 … 26.4 V DC
• Power Consumption: 1 W
• Protection Class: IP65
