Manufacturer: FESTO
Type: Mini slide
Model: SLT-6-20-P-A
Part No.: 170550

Stroke: 20 mm
Adjustable end-position range/length: 7 mm
Piston diameter: 6 mm
Operating mode of drive unit: Yoke
Cushioning: P, Flexible cushioning rings/plates at both ends
Assembly position: Any
Guide: Ball bearing cage guide
Position detection: For proximity sensor
Operating pressure: 1.5 … 10 bar
Mode of operation: double-acting
Operating medium: Compressed air
Material housing: Wrought Aluminium alloy
Connection: 5 mm
