Festo FBSD-GD-9-5POL Plug Socket
The Festo FBSD-GD-9-5POL is a robust plug socket designed for reliable electrical connections in industrial automation. Featuring a 5-pin straight socket with screw terminal design, high protection rating, and durable materials, it ensures safe operation even in harsh environments.
Manufacturer: Festo
Type: Plug Socket
Model: FBSD-GD-9-5POL
Part No.: 18324
Code: WAD 3102491350
Technical information
- Type of Mounting: Via union nut
- Electrical Connection: 5-pin / Straight socket / Screw terminal / Type A / M12x1
- Operational Voltage Range DC: 60 V
- Operational Voltage Range AC: 60 V
- Current Rating at 40 °C: 4 A
- Immunity to Surge: 1.5 kV
- Cable Fitting: Pg 9
- Permissible Cable Diameter: 6 mm / 8 mm
- Connection Cross Section: 0.75 mm²
- Degree of Protection: IP67
- Ambient Temperature: -40 °C / +85 °C
- Material Union Nut: Die-cast zinc / Nickel-plated
- Material Electrical Contact: Bronze / Nickel-plated and gold-plated
