FESTO OS-1/2 OR GATE
The FESTO OS12 is a high-performance OR gate designed for pneumatic systems, enabling reliable logic control with compressed air. Built to operate under varied pressure and temperature ranges, it offers robust construction and efficient air handling with threaded G1/2 connections.
Manufacturer: FESTO
Type: OR Gate
Model: OS-1/2
Part No.: 3427
Technical Information
- Fluid: Compressed Air
- Working Pressure: 1 / 10 bar
- Standard Flow Rate: 5000 l/m
- Pneumatic Connection: G1/2, Threaded
- Type of Mounting: With through valve
- Nominal Width: 12 mm
- Fluid Temperature Range: “10 / 60°C
