Manufacturer: FESTO
Type: Guided Actuator
Model: DFM-25-30-B-PPV-A-KF
Part No.: 532317

Position sensing: For proximity sensor
Guide: Sliding guide,Recirculating ball bearing guide
Piston Diameter: 25 mm
Stroke: 30 mm
Operating Pressure: 1.5 … 10 bar
Max. Pressure: 10 bar
Connection: G1/8
Drive unit operating mode: yoke
Mode of Operation: Double-acting
Ambient Temperature: -20…120 °C
Materials: Wrought aluminium alloy
Piston rod material: High-alloy stainless steel
