Product Overview

Manufacturer: Festo

Type: Proximity Sensor

Model: SMT-10M-PS-24V-E-0,3-L-M8D

Part No.: 551375

The Festo SMT-10M-PS-24V-E-0,3-L-M8D Proximity Sensor is designed for position measurement using the magnetoresistive principle. It operates with a nominal voltage of 24 V DC and supports an operating voltage range from 5 to 30 V DC. The sensor provides a PNP switching output with a normally open function and ensures high switching accuracy with a repetition accuracy of ±0.1 mm. The sensor’s maximum output current is 100 mA, and its maximum switching capacity is 2.8 W. The device offers robust protection with an IP65/IP68 rating, making it suitable for use in demanding environments.

Key Specifications:

• Design: For round slot
• Measured Variable: Position
• Measuring Principle: Magnetoresistive
• Nominal Operating Voltage: 24 V DC
• Operating Voltage Range: 5 … 30 V DC
• Max. Output Current: 100 mA
• Switch Output: PNP, Normally Open
• Max. Switching Capacity DC: 2.8 W
• Max. Switching Capacity in Mounting Kits: 1.5 W
• Protection Class: IP65, IP68
• Housing Material: PA-reinforced High Alloy Steel, Non-corrosive
• Ambient Temperature: -40 … 70 °C
• Max. Tightening Torque: 0.4 Nm
• Switching Output Repetition Accuracy: ±0.1 mm

With its reliable switching performance and robust design, the Festo SMT-10M-PS-24V-E-0,3-L-M8D Proximity Sensor is ideal for industrial applications requiring precise position detection in harsh environments.
