FESTO BMCH-3-3-1/8 MULTIPLE SINGLE SOLENOID VALVE

The FESTO BMCH-3-3-1/8 is a robust and compact multiple single solenoid valve engineered for versatile air control in industrial pneumatic systems. Designed with three 3/2-way monostable valves, this unit features reliable electrical actuation and high durability under demanding conditions.

Manufacturer: FESTO
Type: Multiple Single Solenoid Valve
Model: BMCH-3-3-1/8
Part No.: 6687

Technical Information

• Fluid: Air
• Valve Function: 3x 3/2-Way, Monostable, Closed
• Design: Poppet Valve with Return Spring
• Type of Actuation: Electrically
• Operating Pressure: -0.95 to 7 bar
• Pilot Pressure: 0 to 7 bar
• Flow Rate: 160 l/min
• Plug Diameter: 11 mm
• Pneumatic Connection: G1/4 / G1/8
• Material: Aluminum
• Protection Class: IP65
• Ambient Temperature: -5 to 40 °C
