FESTO MFH-3-1/4-S SINGLE SOLENOID VALVE
The FESTO MFH-3-1/4-S is a high-performance single solenoid valve designed for fast and precise pneumatic control. Engineered with a poppet seat design and robust die-cast aluminium body, this valve supports high flow rates and reliable operation under varying industrial conditions.
Manufacturer: FESTO
Type: Single Solenoid Valve
Model: MFH-3-1/4-S
Part No.: 7959
Technical Information
- Fluid: Air
- Design: Poppet seat
- Function: 3/2-way, closed, monostable
- Type of Actuation: Electrically
- Operating Pressure: -0.95 to 10 bar
- Pilot Pressure: 1 to 8 bar
- Nominal Flow Rate: 800 l/min
- Pneumatic Connection: G1/4
- Material: Die-cast aluminium
- Ambient Temperature: -5 to 40 °C
