Manufacturer: FESTO

Type: Linear Drive

Model: DGP-40-450PPVA-B

Part No: 161782

Materials

• Cover: Aluminum
• Seals: NBR TPE-U(PU)

Piston Diameter: 40 mm

Cushioning: Adjustable at Both Ends

Stroke: 450 mm

Cushioning Length: 30 mm

Operating Pressure: 1.5…8 bar

Theoretical Force At 6 Bar, Retracting: 754 N

Theoretical Force At 6 Bar, Advancing: 754 N

Ambient Temperature: -10…60 °C

Pneumatic Connection: G1/4

Constructional Design: Pneumatic Linear Drive with Slide

Mode of Operation: Double-Acting

Guide: Recirculating Ball Bearing Guide

Position Sensing: For Proximity Sensor

Magnet: with Magnet

Type of Mounting: with Accessories

Weight: 5.00 kg
