FMS LMGZ310.581558.H15 TENSION CONTROL

Tension Control

FMS LMGZ310.581558.H15 Tension Control is a high-precision sensor built for industrial tension measurement applications. With a sensitivity of 1.8 mV/V, a nominal force of 12 kN, and stainless steel construction, it delivers reliable and accurate performance in demanding environments.

SKU: 1073140 Category: Tags: , , , , , , , , , , , , , , , , , ,
In stock: 1 pcs
Very low
Hurry! Only 1 left in stock.
Add to quote

FMS LMGZ310.581558.H15 Tension Control

The FMS LMGZ310.581558.H15 Tension Control is a high-precision tension measurement device designed for industrial applications requiring accurate force monitoring. Engineered with stainless steel construction, it ensures durability, reliability, and stable performance. With a high measuring range and excellent sensitivity, this sensor provides precise tension control in demanding environments.

  • Manufacturer: FMS
  • Type: Tension Control
  • Series: LMGZ
  • Model: LMGZ310.581558.H15
  • Ref No: 00.000.313-513473

Technical Specifications

  • Sensitivity: 1.8 mV/V
  • Tolerance of Sensitivity: ± 0.2 %
  • Accuracy Class: ± 0.3 %
  • Measuring Range: 100:1
  • Temperature Coefficient: ± 0.1 %
  • Temperature Range: –10 to +60 °C
  • Protection Class: IP42
  • Input Resistance: 350 Ω
  • Power Supply: 1 to 10 VDC
  • Sensor Material: Stainless Steel
  • Nominal Force: 12 kN
  • Dimensions (Diameter x Length x Height): 225 x 76 x 258 mm
  • Port Size: G1/2
Weight15,8 kg
