Manufacturer: GRUNDFOS
Type: Circulator Pump
Model: ALPHA2L 15-60 CIL2
Part No.: 96989668
10001499

Maximum discharge head: 60 dm
Temperature class: 110
Pump housing: Grey cast iron
Pump housing: ASTM A48M-150B
Impeller material: Composite material
Ambient temperature: 0 .. 40 °C
Max. operating pressure: 10bars
Connection type: G
Connection size: 33 mm
Nominal pressure level: PN10
Port-to-port length: 130mm
Minimum power consumption P1: 5W
Power consumption P1: 45W
Grid frequency: 50Hz
Rated voltage: 1 x 230V
Maximum power consumption: 0.05 .. 0.38 A
Degree of protection (according to IEC 34-5): IP42
