HAGER EPN 510 LATCHING RELAY

hager-EPN-510-latching-relay-(used)
hager-EPN-510-latching-relay-(used)-1
hager-EPN-510-latching-relay-(used)-2
hager-EPN-510-latching-relay-(used)
hager-EPN-510-latching-relay-(used)-1
hager-EPN-510-latching-relay-(used)-2
Used
Manufacturer: HAGER

HAGER EPN 510 LATCHING RELAY

Latching Relay

The Hager EPN510 is a DIN-rail mounted latching relay with 1 × NO contact, 230 V AC control voltage, and 16 A switching capacity. Compact design, IP20 protection, and RoHS compliance make it ideal for modern electrical installations.

SKU: 1082117 Category: Tags: , , , , , , , , , , , , , , ,
In stock: 1 pcs
Very low
Hurry! Only 1 left in stock.
Add to quote

Hager EPN510 Latching Relay

The Hager EPN510 is a compact and efficient latching relay designed for reliable switching operations in residential, commercial, and industrial installations. With a DIN-rail mounting style, it ensures easy integration into control panels and offers energy-efficient functionality by consuming minimal quiescent current.

Manufacturer: Hager
Type: Latching Relay
Model: EPN510
EAN No.: 3250612369614
Code: JL367

Technical Information

  • Contact Configuration: 1 × NO (Normally Open)
  • Control Voltage: 230 V AC, 50 Hz
  • Rated Switching Current: 16 A (AC1)
  • Quiescent Current: 6 mA
  • Lamp Load Capability (Fluorescent): 800 VA / 900 VA
  • Mounting Style: DIN-rail
  • Operating Temperature: -5 °C to +40 °C
  • Protection (IP rating): IP20
  • Certifications: RoHS, EN 60669-1/2
  • Dimensions: 83 x 17.5 x 63 mm
Weight0,12 kg
