Type: Integrated Chip
Model: HEF4001BP
Part No.: 953930PS / HNN9440P3

Features:
-Fully static operation
-5 V, 10 V, and 15 V parametric ratings
-Standardized symmetrical output characteristics
-Complies with JEDEC standard JESD 13-B
-Inputs and outputs are protected against electrostatic effects
Supply voltage: 3 … 15 V
No. of Inputs: 2
Quiescent Current Max: 1 µA
Current – Output High, Low: 3.4mA, 3.4mA
Input Logic Level – Low: 1.5 … 4 V
Input Logic Level – High: 3.5 … 11 V
Max Propagation Delay @ V, Max CL: 40ns @ 15V, 50pF
Mounting Type: Through Hole
Operation temperature: -40 … 125°C
