HEIDENHAIN INDRAMAT ECN131351262S1271I2C03 ABSOLUTE ENCODER

The ECN1313 series absolute encoder from HEIDENHAIN INDRAMAT delivers precise positioning with a high resolution of 8192 PPR. Engineered for robust performance in industrial applications, this encoder ensures high accuracy, reliability, and long-term durability under demanding conditions.

Manufacturer: HEIDENHAIN INDRAMAT
Type: Absolute Encoder
Model: ECN131351262S1271I2C03
Id. No.: 37780712
SN: 12 273 322
REF NO: HSF03SN-H / 276556-26384

Technical Information

• Series: ECN 1313
• Shaft Diameter: 9.25 mm
• Line Count: 512
• Position Values Per Revolution: 8192 PPR (13 bits)
• Max Speed: 1500 rpm
• Incremental Signals: 1 VPP
• Shaft Design: Tapered Shaft
• Communication Interface: EnDat01
• Voltage Supply: 3.6 / 14 V DC
• Max Current Consumption: 85 mA
• Max Power Consumption: 0.6 / 0.7 W
• Electrical Connection: Connector 12-Pin
• Face Diameter: 64.8 mm
• Back Diameter: 56 mm
• Protection Class: IP40
• Operating Temperature: -40 / 115 °C
