Heidenhain ROD 426 5000 03S12-03 Incremental Encoder

The Heidenhain ROD 426 5000 03S12-03 is a high-precision incremental encoder designed for reliable position and speed feedback in demanding industrial automation systems. Featuring a solid shaft design, TTL driver, and high pulse resolution, it ensures accurate signal output and long-lasting durability.

Manufacturer: Heidenhain
Type: Incremental Encoder
Model: ROD 426 5000 03S12-03
ID No.: 376 846-ST S3
SN: 48 955 596 B

Technical information

• Voltage: 5 V (±10 %)
• Driver: TTLx2
• Flange Design: Synchro flange
• Shaft Design: Solid shaft
• Shaft Diameter: 6 mm
• Resolution: 5000 pulses per revolution (PPR)
• Max. Current Consumption: 120 mA
• Max. Speed: 16000 rpm
• Max. Pulse Frequency: 300 kHz
• Protection Class: IP67 at housing, IP64 at shaft inlet (IP66 upon request)
• Max. Temperature: 100 °C
