Manufacturer: IFM
Type: Capacitive sensor
Model: KB5002
MRN: KB-3020-APKG/NI

Electrical design: PNP
Output function: normally closed
Sensing range[mm]: 3…20
Housing: cylindrical
Materials: PBT
Dimensions[mm]: Ø 34 / L = 81
Operating voltage[V]: 10…36 DC
Current consumption[mA]: 13; (24 V)
Protection class: II
Max. voltage drop switching output DC[V]: 2.5
Permanent current rating of switching output DC[mA]: 250
Switching frequency DC[Hz]: 40
Correction factor: glass: 0.4 / water: 1 / ceramics: 0.2 / PVC: 0.2
Connection: Cable: 2 m, PVC; 3 x 0.5 mm²
Ambient temperature[°C]: -25…80
Protection: IP 67
