Manufacturer: Schaeffler INA

Type: Tow-Row Linear Recirculating Ball Bearing Carriage

Model: KWE25 G3 V1

Size: 25 mm

Basic Load Ratings:

Dynamic C: 16200 N

Static C₀: 20900 N

Static Moment Rating About:

X axis M_0x: 253 Nm

Y axis M_0Y: 185 Nm

Z axis M_0Z: 185 Nm

Preload: V1

Accuracy Class: G3

Dimensions:

Height system H: 36 mm

Width carriage A: 70 mm

Overall length carriage C: 80.7 mm

A₂: 57 mm

C₂: 45 mm
