Manufacturer: INA Schaeffler
Type: Support Roller (Yoke-Type Track Roller)
Model: NUTR 45100 X

Dimensions
Bore Diameter d: 45 mm
Outer diameter D: 100 mm
Total Width: 32 mm
Basic dynamic load rating: 73,000 N
Basic static load rating: 114,000 N
Fatigue load limit, radial: 16,100 N
Speed on permanent grease lubrication: 1,400 1/min
Permissible static load, radial: 114,000 N
Radial internal clearance: Between C2 and CN
Sealing: Labyrinth Seal on both sides
