Leuze Electronic CPT400/3/T1 Safety Light Curtain, Transmitter

The **Leuze Electronic CPT400/3/T1** is a high-performance safety light curtain transmitter from the **COMPACTplus series**. Designed for industrial safety applications, it provides reliable protection with a sensing range of up to 18 meters and an IP65 degree of protection. This Type 4 light curtain meets IEC/EN 61496 standards for safety functions in hazardous environments.

Manufacturer: LEUZE ELECTRONIC

Type: Safety Light Curtain, Transmitter

Series: COMPACTplus

Model: CPT400/3/T1

Order No.: 68823000

Technical Data:

• Type in accordance with IEC/EN 61496: Type 4
• Sensing Range: 0 “ 18 m
• Beam Number: 3
• Beam Spacing: 400 mm
• Operating Voltage: 24 VDC
• Operating Temperature: 0 / 55 °C
• Degree of Protection: IP65
