Manufacturer: Mavilor

Type: AC Servo Motor

Model: BLS072

Ref. No.: BS072A.00.310N.00

Nominal Speed [rpm]: 11000

Stall Torque [Nm]: 1.9

Peak Torque [Nm]: 7.6

EMF Constant [Vs/rad]: 0.28

Torque Constant [Nm/A]: 0.28

Radial Load [N]: 245

Axial Load [N]: 98

Brake Voltage [VDC]: 24

Brake Torque [Nm]: 1.5

Ambient Temperature [°C]: 25

Resolver: 2T8

Protection Class [IP]: 65

Mounting Position: B5

Insulation Class: F

Weight [kg]: 2.32
