Manufacturer: MERKLE

Type: Hydraulic Block Cylinder

Model: BZ500.25/16.01.9.201.060

KOM No.: 20054640

Art No.: 091236

Piston Diameter: 25 mm

Rod Diameter: 16 mm, on both side

Stroke: 60 mm

Cylinder Shape: Rectangle

Mode of operation: Double-Acting

Maximum operating pressure: max. 500 bar

Piston rod thread: Female

Temperature range: 0 …. 180 °C

Connection: ¼ G

Weight: 2.2 kg
