Manufacturer: M.D. Micro Detectors

Type: Photoelectric Sensor

Series: SA

Model: SA6/0P-1K



Function: Diffuse Reflection

Nominal Sensing Distance: 400 mm

Emission: Infrared (880 nm)

Operating Voltage: 10 … 30 V DC

Load Current: 100 mA

No-Load Supply Current: 35 mA

Output Type: NO

Electrical Design: PNP

Power on Delay: 200 ms

Switching Frequency: 1000 Hz

Ambient Temperature: -25 … 70 °C

Degree of Protection: IP67

Connection: Right Angle Plug (M12 4-Pin)

Housing: Metal

Optic Material: PMMA

Diameter, Housing Length: M18 x 1, 79 mm

Weight: 0.07 kg
