Manufacturer: MICRO SWITCH
Type: Micro Switch
Model: BZE6-2RQ9
Part No: 7820

Series: E6
Rated Operational Voltage: 125 / 250 V AC/DC / 480 / 600 V AC
Rated Operational Current:
125 / 250 / 480 V AC: 15 A
600 V AC: 2 A
125 V DC: 1/2 A
250 V DC: 1/4 A
Horse Power:
125 V AC: 1/2 A
250 V AC: 1/4 A
Contact: SPDT, 1 Normally Open (NO) + 1 Normally Closed (NC)
Operating Force: 2.50 … 3.62 N
Actuator Type: Roller Plunger
Actuator Length: 5.2 mm
Mounting: Side
Material: Zinc Die-Cast
Temperature: -32 … 71 °C
Dimensions: 49.6 x 77.2 x 25.4 mm
