MONITRAN MTN/1187Q-5 Accelerometer

The **MONITRAN MTN/1187Q-5** accelerometer is designed for precise measurement of vibration and acceleration in various industrial applications. With a robust stainless steel case and a broad operating temperature range, this sensor ensures reliable performance in challenging environments.

Manufacturer: MONITRAN

Type: Accelerometer

Model: MTN/1187Q-5

MRN: N421999000003

Serial No: 585322

Technical Data:

• Output Current: 4-20mA DC
• Supply Voltage: 12-32V DC (4-20mA)
• Frequency Response: 2Hz to 1kHz ±10%
• Mounted Base Resonance: 5kHz (nominal)
• Isolation: Base isolated
• Dynamic Range: 50g peak
• Transverse Sensitivity: Less than 5%
• Operating Temperature: -25 to 90°C
• Temperature Sensitivity: 0.08%/°C
• Case Material: Stainless steel
• Mating Connector: MTN/MH008
• Mounting Torque: 8Nm
• Sealing: IP67
• Dimensions: Diameter 27 mm, Length 57 mm
