NADELLA FG1535EE CAM FOLLOWER

Needle Cam Follower with Convex Outer Ring

Nadella FG1535EE Needle Cam Follower features a 15 mm bore diameter and 35 mm outer diameter, with a total width of 19 mm. It comes with plastic seals for added protection, making it ideal for smooth and reliable operation.

SKU: 1076998 Category: Tags: , , , , , , , , , , , , , , ,
In stock: 4 pcs
Low stock
Only 4 items remaining.
Add to quote

Nadella Needle Cam Follower with Convex Outer Ring FG1535EE

The Nadella Needle Cam Follower with Convex Outer Ring FG1535EE is designed for high load-bearing capacity and smooth operation. With a dynamic load rating of 12200 N and a static load rating of 25600 N, it is ideal for demanding industrial applications.

Manufacturer: Nadella

Model: FG1535EE

Type: Needle Cam Follower with Convex Outer Ring

Technical Information:

  • Bore Diameter (d): 15 mm
  • Outer Diameter (D): 35 mm
  • Width, Total: 19 mm
  • Basic Capacity: 18000 N
  • Dynamic Load (C): 12200 N
  • Static Load (C0): 25600 N
  • Speed Limit (Grease): 3750 rpm
  • Sealing: EE, Series with Plastic Seals
Weight0,1 kg
