Manufacturer: NATIONAL INSTRUMENTS

Type: USB MULTIFUNCTION DEVICE

Model: NI USB-6008

part no: 191039D-02L

Analog input Differential: 4

Analog input Single-ended: 8, software-selectable

Input resolution

Differential: 12 bits

Single-ended: 11 bits

Maximum sample rate (aggregate): 10 kS/s, system dependent

Converter type: Successive approximation|

Timing resolution: 41.67 ns

Analog outputs: 2

Output resolution: 12 bits

Maximum update rate: 150 Hz, software-timed

Output range: 0 V to +5 V

Output impedance: 50 Ω

Output current drive: 5 mA
