NTN 1215S K C3 Self-Aligning Ball Bearing
The NTN 1215S K C3 Self-Aligning Ball Bearing is engineered for applications requiring smooth operation and misalignment compensation. With a high load capacity, C3 clearance class, and optimal speed ratings, this bearing ensures reliability in industrial environments.
- Manufacturer: NTN
- Type: Self-Aligning Ball Bearing
- Model: 1215S K C3
Technical Information
- Bore Diameter (d): 75 mm
- Outer Diameter (D): 130 mm
- Width (B): 25 mm
- Basic Load Ratings:
- Dynamic (Cr): 39 kN
- Static (C0r): 15.7 kN
- Fatigue Limit Load: 0.63 kN
- Limiting Speed:
- Oil: 5300 rpm
- Grease: 4300 rpm
- Clearance Class: C3
