NTN 1316K SELF-ALIGNING BALL BEARING

Self-Aligning Ball Bearing

NTN 1316K self-aligning ball bearing features an 80 mm tapered bore with a 170 mm outer diameter and pressed steel cage. Rated for 89 kN dynamic load and 4300 RPM with oil lubrication.

SKU: 1076046 Category: Tags: , , , , , , , , , , , , , , ,
In stock: 1 pcs
Very low
Hurry! Only 1 left in stock.
Add to quote

NTN 1316K Self-Aligning Ball Bearing

Built to accommodate shaft misalignment and dynamic loads, the NTN 1316K self-aligning ball bearing is designed for stable, high-speed performance in demanding environments.

Manufacturer: NTN

Type: Self-Aligning Ball Bearing

Model: 1316K

Technical Information:

  • Bore Diameter (d): 80 mm
  • Outer Diameter (D): 170 mm
  • Width: 39 mm
  • Dynamic Load Rating: 89 kN
  • Static Load Rating: 33 kN
  • Limiting Speed (Oil): 4300 RPM
  • Limiting Speed (Grease): 3600 RPM
  • Bore Type: K, Tapered Bore
  • Cage Type: Pressed Steel
Weight4,2 kg
