NTN 6004ZZCM 5K “ Deep Groove Ball Bearing
The NTN 6004ZZCM 5K deep groove ball bearing is engineered for precision and high-load applications. It features a shielded design for protection and a reliable pre-lubrication system. This bearing is ideal for applications with demanding operational conditions, such as those involving high speeds and varying temperatures.
- Manufacturer: NTN
- Type: Deep Groove Ball Bearing
- Model: 6004ZZCM 5K
Technical Information:
- Bore Diameter (d): 20 mm
- Outer Diameter (D): 42 mm
- Width (B): 12 mm
- Min Fillet Radius (rs): 0.6 mm
- Dynamic Load Rating (Cr): 10,400 N
- Static Load Rating (C0r): 5,050 N
- Fatigue Load Limit: 355 N
- Reference Thermal Speed: 18,000 tr/min
- Pre-lubricant: 5K, Kyodo Yushi Multemp SRL
- Sealing: ZZ, Shielded on both sides
- Cage: Pressed steel
- Radial Clearance Class: CM
- Operating Temperature: -40 to 150°C
