NTN Oval Flanged Housing Unit AELPFL204W3
The NTN Oval Flanged Housing Unit AELPFL204W3 is designed for reliable performance in various industrial applications. It features an eccentric locking collar, an oval flange mounting, and high load capacity for optimal function in demanding environments.
Manufacturer: NTN
Type: Oval Flanged Housing Unit
Model: AELPFL204W3
Bearing Number: AEL204W3
Housing Number: PFL204
Technical Information:
- Bore Diameter (d): 20 mm
- Overall Length (L): 67 mm
- Overall Height (H): 90 mm
- Width of Inner Ring (B1): 31 mm
- Distance Between Attachment Bolts (J): 71.5 mm
- Maximum Load: 3000 rpm
- Mounting: Oval Flange
- Bolt Size: M8
- Locking Device: Eccentric Locking Collar
