Omron F3S-TGR-CL4A-K3C-800 Multi-Beam Safety Sensor
The Omron F3S-TGR-CL4A-K3C-800 is a high-performance multi-beam safety sensor designed for active/passive systems. It provides reliable object detection and personnel protection in industrial automation, with an IP65 protection rating and long detection range.
- Manufacturer: Omron
- Type: Multi-Beam Safety Sensor
- Model: F3S-TGR-CL4A-K3C-800
Technical Information:
- System: Active/Passive
- Response Time: 13 ms
- Operating Distance: 0.5 – 8 m
- Detection Capability: 400
- Operating Temperature: -10 to 55 °C
- Supply Voltage: 24 VDC ±20%
- Power Consumption: 10 W
- Degree of Protection: IP65
- Resolution: 800 mm
