Manufacturer: Pepperl Fuchs

Series: VariKont

Type: Inductive Sensor

Model: NJ20U1A2

Rated Operating Distance: 20 mm

Assured Operating Distance: 0 … 16.2 mm

Operating Voltage: 10 … 30 V DC

Operating Current: 200 mA

Switching Frequency: 0 … 150 Hz

Electrical Design: PNP

Switching Output: Normally Open and Normally Closed

Connector Type: Terminal Compartment

Enclosure Rating: IP68

Ambient Operating Temperature: -25 … 70°C

Dimensions: 40 x 40 x 118 mm

Housing: Rectangular

Housing Material: PBT

Sensing Face Material: PBT

Mounting: Flush Mountable
