IMI NORGREN M146132M760 ROADLESS CYLINDER

The IMI Norgren M146132M760 from the Lintra Plus series is a high-performance roadless cylinder engineered for durability, precision, and smooth motion in demanding pneumatic applications. Designed with a double-acting mechanism and external guiding system, it delivers reliable operation even under continuous use. Manufacturer: IMI Norgren
Type: Roadless Cylinder
Model: M146132M760
Ref. Code: J13DS
Series: Lintra Plus

Technical Information

Medium: Compressed air
Operating Pressure: 1 to 8 bar
Guiding System: External
Operation: Double acting
Cylinder Diameter: 32 mm
Stroke: 760 mm
Operating Temperature: max. 80 °C
Connection: G1/4
Materials “ Barrel: Anodized aluminum
Materials “ Piston Head Seals: Polyurethane
Materials “ Seals: NBR
