TELEMECANIQUE CA2-FN 144 / CA2-FN/FK Contactor

The TELEMECANIQUE CA2FN144 / CA2-FN/FK is a robust 8-pole contactor from the CA2 series, engineered for reliable switching and control in industrial electrical systems. With high operational voltage capacity, multiple contact configurations, and compliance with international standards, it ensures dependable performance in demanding environments.

Manufacturer: TELEMECANIQUE
Type: Contactor
Model: CA2-FN 144 / CA2-FN/FK
Series: CA2

Technical Information

• Rated Coil Voltage: 110 / 120 V AC
• Rated Operational Voltage: 500 V AC
• Rated Operational Current: 10 A
• Frequency: 50 / 60 Hz
• Power: 0.75 / 1.5 kW
• Poles No.: 8-Pole
• Contact: 4 Normally Open (NO) + 4 Normally Closed (NC)
• Protection Class: IP20
• Ambient Temperature: -40 / 60 °C
• Dimensions: 150 x 130 x 130 mm
• Standards: IEC 255-1 / ICE 158-1
