Telemecanique LC1 D4011 Contactor with LX1 D6 B7 Coil

The Telemecanique LC1 D4011 is a high-performance 3-pole contactor built for demanding industrial applications. Paired with the LX1 D6 B7 24V AC coil, it offers powerful switching capabilities, robust voltage resistance, and consistent operation in high-load circuits.

• Manufacturer: Telemecanique
• Type: Contactor
• Model: LC1 D4011

Technical Information:

• Rated Insulation Voltage (Ui): 1000 V
• Rated Impulse Withstand Voltage (Uimp): 8 kV
• Rated Power: 22 kW at 500V AC / 30 kW at 690V AC
• Thermal Current (Ith): 60 A
• Continuous Current: 60 A
• AWG: 3 / 10 CU
• Torque: 45 lb.in
• Number of Poles: 3

Attached Coil Information:

• Manufacturer: Telemecanique
• Type: Contactor Coil
• Model: LX1 D6 B7
• Coil Voltage: 24V AC
• Frequency: 50 / 60 Hz
