Eurotherm / Schneider Electric TC2000 Two-Phase Solid-State Relay

The Eurotherm / Schneider Electric TC2000 is a powerful two-phase solid-state relay designed for high-performance industrial applications. Engineered with advanced protection and filtering, it ensures reliable switching, high current handling, and safe integration into demanding electrical systems.

Manufacturer: Eurotherm / Schneider Electric
Type: Two-Phase Solid-State Relay
Model: TC2000 02/150A/440V/220V/0MA20/000/GER/-/FUSE/FILT/NONE/-//00
Serial No.: AT21634 – 1 – 1 – 08 – 04
Part No.: 8368*3042815 / 175763

Technical information

• Auxiliary Supply: 220 V
• Rated Current: 150 A @ 45 °C
• Input: 0 to 20 mA DC
• Rated Voltage (Ue): 440 V / 220 V
• Rated Operational Frequency: 47 to 63 Hz
• Fuse: LA172468U200
• Load Configuration: Three phase loads
• EMC Filter: Filter
• Spare Fuse: 150 A rating, 200 A fuse rating

Attachment

• Bussmann 170M3465: Square body flush end contact high speed fuse
• Code: 1*BKN/50, 040623/0244
• Current: 200 A
• Rated Voltage: 690 / 700 V (IEC/UL)
• Resistance: 0.6274 mΩ (21 °C)
