Manufacture: Relpol
Type: Interface relay
Model: PI61P24VDC

Input voltage: 24 V DC
Rated continuous current IU: 6 A
Rated continuous voltage: 250 V AC
Rated power consumption: 0,3 … 0,7 W
Insulation rated voltage: 400 V AC
Insulation pollution degree: 3
Operating time (typical value): 6 ms
Output contact: 1 change over contact (CO)
Contact material: AgSnO₂
Min. switching current: 100 mA
Max. inrush current: 10 A (20 _ms)
Protection category: IP20
Ambient Operation temperature: -40 … 55°C
Dimensions: 93,8 x 6,2 x 80 mm
