New

Manufacturer: REXROTH

Rexroth Linear Motion Technology

REXROTH R069602000 TORQUE RESISTANT BUSHING

Name: REXROTH R069602000 TORQUE RESISTANT BUSHING
SKU: 1076622
Availability: InStock

Torque Resistant Bushing

Rexroth KBDR1-20 Torque Resistant Bushing features a 20 mm shaft diameter and 32 mm outer diameter. It offers 1550 N dynamic load rating and 7.5 Nm torsional moment load capacity, ideal for applications requiring high torque resistance.

SKU: 1076622 Category: Rexroth Linear Motion Technology Tags: 1550, 20, Bushing, diameter, Dynamic, Industrial., KBDR1-20, Load, mm, moment, N, R069602000, Resistant, Rexroth, shaft, Torque, Torsional

In stock: 3 pcs

Very low

Hurry! Only 3 left in stock.

Add to quote

Description
Additional information

Rexroth Torque Resistant Bushing KBDR1-20

The Rexroth Torque Resistant Bushing KBDR1-20 (MNR: R069602000) is engineered to provide high torque resistance in applications requiring reliable performance under load, featuring high dynamic and static load ratings.

Manufacturer: Rexroth

Type: Torque Resistant Bushing (KBDR1-20)

MNR: R069602000

Technical Information:

Shaft Diameter (d0): 20 mm
Outer Diameter: 32 mm
Length of Linear Bushing: 45 mm
Rows of Balls: 5
Raceway Groove: 1
Dynamic Load Rating: 1550 N
Dynamic Torsional Moment Load Capacity (Mt): 7.5 Nm
Static Load Rating: 1050 N

Weight	0,1 kg
Condition	New
Manufacturer	REXROTH
Shelf No.	250531
Type of Product	Torque Resistant Bushing
MNR	R069602000

REXROTH R069602000 TORQUE RESISTANT BUSHING

REXROTH R069602000 TORQUE RESISTANT BUSHING

Torque Resistant Bushing

Rexroth Torque Resistant Bushing KBDR1-20

Technical Information:
