Manufacturer:  MANNESMANN REXROTH

Type: Pressure Relief Valve Pilot Operated

Model: DBW 30 B2-52/100Y6AG24NZ5L

MNR: R900515651

Size: 30

Adjustment Element for Pressure Adjustment: Sleeve with Hexagon and Protective Cap

Pressure Setting: 100 bar

Ambient Temperature Range: –30 …. +50 ^oC

Maximum Operating Pressure at Ports P, X :350 bar

Maximum Operating Pressure at Port T :315 bar

Maximum Backpressure at Ports Y, T : 210 with DC solenoid

160 with AC solenoid

Maximum Flow Rate: 650 l/min

Hydraulic Fluid Temperature Range: –30 …. +80 ^oC

Viscosity Range: 10 … 800 mm²/s

Connection: Sup-plate

Weight: 1.21 kg
