Rexroth VT 11011-12 Servo Amplifier

The Rexroth VT 11011-12 is a high-quality servo amplifier designed for precision control in industrial automation. With stable performance, compact dimensions, and reliable protection features, it ensures accurate signal processing and dependable operation.

Manufacturer: Rexroth
Type: Servo Amplifier
Model: VT 11011-12
MNR: R900010958
Serial No.: E812903.043.0.a
Code: 05W48/ 7087
CS: 13310045

Technical information

• Operating Voltage: 24 V DC
• Power Consumption: 36 VA
• Input Voltage Range: 0 to 10 V
• Adjustment Ranges:
• Output Current: 0.75 A to I max
• Ramp Time: approx. 50 ms to approx. 5 s
• Type of Connection: 12 screw terminals
• Type of Protection: IP 20
• Dimensions: 40 x 79 x 85.5 mm
• Permissible Operating Temperature Range: 0 to +50 °C
