Manufacturer: RODOBAL
Type: Rod End, Female thread
Model: RF 14

Dimensions
Bore Diameter d: 14 mm
Outer diameter D: 36 mm
Width B: 19 mm
Thread designation: M14x2
Sliding contact surface combination: Steel/Steel
Attachment feature, rod end shank: Right-hand female thread
Static Max.
Radial: 2450 daN
Axial: 1340 daN
