Manufacturer: FAG
Type: Angular contact ( Spindle )Ball Bearing
Model: B7010 C T PA HG UL
Bore Diameter: 50 mm
Outer Diameter: 80 mm
Thickness: 16 mm
Chamfer rmin: 1 mm
Contact angle: 15°
Basic load ratings:
Dynamic Cr: 28500 N
Static C0r: 22800 N
Fatigue limit load: 1660 N
Limiting speeds: Grease 17000 rpm, Oil 28000 rpm
Material: Bearing steel
Bearing arrangement: Single bearing Arrangement in any combination
Preload: Light
Cage: Laminated fabric, guidance on outer ring
Weight: 0.27 kg
