Manufacture: Saia
Type: Current monitoring
Model: KFE 103

Supply voltage: 230 V AC
Frequency: 50/60 Hz
Consumption Power: 4 VA
Minimum reaction time: 200 ms
Duty cycle: continuous duty
Max. range of input current: 0.1 … 10 A
Time delay: 0.1 … 12s
Max. cable length of input signal measurement cable: 50 m
Contact: 1 Change over contact
Switching capacity AC-1: 8 A/250 V AC
Housing: 35 mm DIN
