Manufacturer: ELAU – SCHNEIDER ELECTRIC

Type: SERVO MOTOR

Model: BCH1002O02A1C

Rated Voltage : 110 V

Max. Current: 36 A

Stall Current: 12 A

Normal Speed: 3000 Revolution Per Minute (rpm)

Max. Speed: 5000 Revolution Per Minute (rpm)

Nominal Torque: 6.37 Nm

Holding Brake: Without

Nominal Power: 2 kW

Flange Size: 100 mm

Motor Length: 199 mm

Shaft Diameter: 22 mm

Shaft Length: 37 mm

Insulation Class: A

Protection Class: IP40

Weight: 6.30 kg
