SCHNEIDER CA3KN31BD CONTROL RELAY

The Schneider CA3KN31BD control relay is part of the reliable TeSys range, offering durable and efficient switching for control circuits. Designed for industrial automation systems requiring high-performance signal switching with compact form factor and high-voltage resistance.

Manufacturer: SCHNEIDER
Type: Control Relay
Model: CA3KN31BD

Technical Information

• Range: TeSys Contact: 3 NO + 1 NC
• Rated Operational Voltage (Ue): 690 V
• Control Circuit Voltage (Uc): 24 V DC
• Thermal Current (Ith): 10 A
• Rated Insulation Voltage (Ui): 690 V
• Rated Impulse Withstand Voltage (Uimp): 8 KV
• Ambient Temperature for Operation: -25 / 50 °C
• Dimensions (H x W x D): 58 x 45 x 57 mm
