Manufacturer: Schneider

Type: Circuit Breaker / Switch Disconnector

Range: Compact

Model: INS250

Part No.: 31106

Number of Poles: 4

Rated Current (I_e): 250 A

Rated Operational Voltage (U_e): 690 V AC / 125 V DC

Rated Insulation Voltage (U_i): 750 V AC 50/60 Hz

Maximum Power:

75 kW (220/240 V AC)

132 kW (380/415 V AC)

210 kW (660/690 V AC)

Mounting Mode: Fixed

Service Frequency: 50/60 Hz

Standards: IEC 60947-3 / IEC 60947-1

Dimensions ( W x D x H): 140 x 96 x 136 mm

Degree Of Protection: IP40

Operation Temperature: -25 … 70 °C

Weight: 2.15 kg
