Manufacturer: Schneider Electric

Type: Universal Input And Analog Output Module

Family: TAC Xenta®

Model: TAC Xenta 451A

Part No: 0-073-0285-0

Supply Voltage: 24 V AC

Transformer Sizing: 6 VA

Universal Inputs: 8

Voltage across Open Contact: 20 V DC

Current through Closed Contact: 3 mA

Analog Outputs: 2

Control Voltage: 0–10 V DC

Control Current, Short-Circuit Proof: Max. 2 mA

Enclosure rating: IP20

Ambient Temperature Operation: 0 … 50 °C

Dimensions: 110 x 90 x 75 mm

Weight: 0.14 kg
